Aqara G4 Doorbell chime mount

Mount for the Aqara G4 Doorbell chime that works with an Apple 5w USB charger.
10
112
2
1268
updated July 23, 2024

Description

PDF

The Aqara G4 Doorbell uses a digital chime and their solution is to adhere it with a sticker to wherever you want. I wanted to mount it near a outlet but also mount it to the power adapter and not stick it to my wall.

I found a mount that was designed to hold the chime but made for EU outlets. I had a extra Apple 5 watt charger laying around so I looked for a model designed to use it. Once I found one I imported both models into Tinkercad and chopped off the pieces I did not need with blocks in the “hole” mode. Once I had the two parts I needed I overlapped them and combined into one piece.

Supports are required, I printed the model with the longer side down on the print bed.

Printed on an Ender 3 v2 using OrcaSlicer (tree supports).

Tags



Model origin

The author remixed this model.

Differences of the remix compared to the original

Combined the chime mount part from one model and the Apple 5w adapter mount from the other model into one.
