Ikea Pax/Komplement Drawer Bottom Mount for Metod Cabinet

Ikea Metod cupboards lack a low height drawer. There is one available in the Pax/Komplement series. However, the Pax standard width of 50cm does not fit the Metod's 60cm. Further, on the bottom of my cupboard, the door hinge got in the way for wider drawers. I saw alternative adapters with wood but thought it would be more convenient to mount the drawer directly to the cupboard bottom. This way all height of Pax drawers can be mounted to any flat ground.

With four of the mount adapters (two of them mirrored) and countersunk screws 3x16mm, the rails are affixed. I first mounted the front adapters with screws below the rail, slid the rails in, and then mounted the rear adapters with screws on the side only. I just glued the white covers onto the rails but they are not really necessary.

Prints without support.
