DIY connection box for ebike controller, wire connection box screw

connection box for ebike wire connection box screw
2
26
0
229
updated April 8, 2024

Description

PDF

connection box for connecting wires of ebike controller to motor

or anything else with round screw ends wires

box is protected from top from shorting

for securing bottom is udes hot glue and two side duct tape

printed 0.2mm layer height, 100% infil, without supports, printed in pla



Video on YouTube of manufacturing
