Voltcraft VC-870 + VC-523 Gridfinity Collection

Custom inserts i made for the 6x7x15 storage box by pred to fit everything i need for Voltcraft VC-870 and VC-523, plus everything needed to use them.

Included are:

• Main “bins” for holding the two Multi-meters also have space for their batteries, a spare fuse and a LTT Pocket Screwdriver plus second bit. (Space usage: 5x3x15)
• A bin for the probes (Space usage: 4x2x6)
• Bin for the power meter adapter for European plug. (Space usage 5x2x15 but with 3x2x6 lowered section)

Additional boxes from other creators:

I also used a number of generic 3x3x6, 3x2x6, 2x1x6 and 2x1x3 bins for organizing cables and other small tools. (I used the openscad bin generator)

Below the VC-523, there is space for a 3x1x3 box with lid

Print Settings:

I printed the models with a 0.4mm nozzle (0.4mm line width).

I used 2 walls, 3 top and bottom layers and 20% lightning infill .

Parametric box is used as the base before cutting out the spaces for the tools.
