Prusa XL modified CoreXY-front-left & CoreXY-front-right with hexagonal pattern

I wanted to reprint the corexy-parts of the Prusa XL in Prusament PC Blend Carbon Fiber and I noticed the big air gap when using the EnXLosure from VOXEL3D. So I simply remixed the original. The inward edge has been made sharper (chamfer removed) to minimize the door gap and because I was already there, I added a matching hexagonal pattern.

I also added a Model with chamfer, like the original one with hex pattern.

Print Settings:

0.2 layer high with 0.4 nozzle and 5 perimeters.

or 0.25 with 0.6 nozzle and 4 perimeters.

Infill 25% Gyroid.

I didn't needed a raft for Prusament PCCF on satin sheet. But maybe you… ;)

No supports!

This might also interest you: https://www.printables.com/de/model/683762-prusa-xl-modified-corexy-back-parts

A hexagonal pattern has been added to the front.
