C14 to Extrusion Mount
Mounts a C14 receptacle to the a 2020 extrusion frame
6
21
0
163
updated April 4, 2024
Description
PDFI designed this simple model to mount this C14 receptacle I bought from Digikey. It mounts to the back of my corexy printer (VzBot) on the 2020 extrusion frame.
Hardware
- Two of each M4 screws and t-nuts to mount to frame. I used M4x12.
- Two of each M3x12 and M3 nuts (I used nylon locking because I'm paranoid) to mount the C14 receptacle to the part.
- Part from digikey
| DigiKey Part Number | 708-2398-ND |
| Manufacturer | Bulgin | |
| Manufacturer Product Number | BVA01/Z0000/01 | |
| Description | PWR ENT MOD RCPT IEC320-C14 PNL | |
| Detailed Description | Power Entry Connector Receptacle, Male Blades - Module IEC 320-C14 Panel Mount, Flange |
