Masuter Pro Lead Screw Carriage Plate

This piece is designed for users to be able to convert their x-axis so that it uses lead screws instead of belts. It makes use of the existing holes for mounting gantry plates and v-wheels. two longer m5 bolts and nuts may be needed to replace the existing screws for the v-wheels.

Attach an 8mm anti-backlash nut to this block using two m5 screws.

Note - The alignment and spacing may not match your use case perfectly, so I would suggest printing a test version with low infill/perimeters to be sure everything aligns as it should. Adjusting z height slightly up or down should help with alignment issues. Then print with as many walls and as much infill as you can.

I'm including the f360 file, but go easy on a noob!

Used this file for the anti-backlash 8mm nut https://www.thingiverse.com/thing:2607994

Lead Screw Gantry Plate used: https://www.etsy.com/listing/1448601794/foxalien-masuter-pro-gantry-plate-svg?click_key=e3247093b7eaf90c30b345d1dae0ba1de8811b2e%3A1448601794&click_sum=523dd170&external=1&ref=hp_opfy-1-1
