hygrometer stand

this stand is designed to fit the small, hygrometer/thermometers everyone seems to have.  it's open at the back to allow air flow and battery changes without removing the hygrometer, and holds the hygrometer at 60° to make it easy to read.

the slot fits a hygrometer measuring under 45mm x 26mm under the bezel.  the retention feature is slightly off center, starting at just over 9mm from the top of the hygrometer, under the bezel, and is under 7mm wide.  NB: despite the off-center retention feature, it is possible to put the hygrometer in upside down.  won't hurt anything, but makes it hard to read.

printing

this model prints without supports if printed face down; no special parameters required.
