Jeti Transmitter Holder DS-12

Printed alternative for: https://shop.jetiusa.com/Jeti-Transmitter-Holder-DS-12-p/mar-hds12.htm
1
49
0
523
updated March 31, 2024

Description

PDF

This is a printed alternative to the item available at:
https://shop.jetiusa.com/Jeti-Transmitter-Holder-DS-12-p/mar-hds12.htm
I decided that the price of the original solution was too high, so I decided to design my own solution.


For assembly you need:
- Folding brackets
(https://www.hacker-motor-shop.com/Transmitter-Receiver-Central-Box-Accessories/JETI-Duplex-tranmitter-accessories/Tray-and-neckstripe/Brackets-2pcs-DC-DS-Tx-DUPLEX -2-4EX.htm?shop=hacker_e&SessionId=&a=article&ProdNr=80001515&p=8220)
- 4x KVT 345M4 threaded insert (but modify the .step model for any solution of your own)
- 4x M4x10 conical screw (for attaching the arms)
- 4x conical screw M4x12 or longer (for screwing printed elements to the device housing)
- 4x M4 self-locking nut (or regular nut + spring washer as in my case).
