A rigid fan mount compatible with some BIQU H2 Ender backplates
4
53
0
279
updated March 21, 2024

Description

PDF

Compatible with my remixed Ender backplate. Recommend printing with PETG.

I've included the step file to make it simpler for remixing.

Model origin

The author remixed this model.

Differences of the remix compared to the original

I changed the mounting so that you don't need to rotate the stepper motor. Added bracing and thickened the top as the original design flexed a bit. I've adapted it fit with back plates that have an H2 support brace 6mm high and 11mm or less width.

This is fan gives excellent part cooling - excellent to 70 degrees overhang in all directions.
