CM4 SI-PEX40064 bracket

This is a bracket I designed to allow the SI-PEX4004 SATA card to be securely mounted to the CM4IO board.
0
12
0
67
updated March 2, 2024

Description

PDF

This is a bracket I designed to allow the SI-PEX4004 SATA card to be securely mounted to the CM4IO board. The PCIe slot with the CM4IO is a bit loose and this can cause the system to crash if the card is wobbled. With this bracket, I have been running the cm4 with this card for months. Use any 2 random screws which fit the holes. I made them extra long so you can use any screw.
