Jigsaw blade handle / improvised handsaw

Handle for common T-type jigsaw blades to use them as a hand tool requiring only 2 M4 bolts and nuts
11
43
1
241
updated May 1, 2024

Description

PDF

This is my take on cheap, improvised hand saws which may be useful for your 3d printing workshop or due to their small size and low weight as a camping tool.

It uses 2 M4x10 bolts and nuts, however to further simplify it, using superglue to join the halves would be possible.

I definitely recommend using a 0.25mm layer height as all parameters are designed with this in mind for a snug fit with the sawblade. I tested it with a short KWB blade and a longer Bosch Professional blade.

You may want to use more perimeters than usual for this model so that the screws won't damage the part.
