Honeycomb hex bit storage

10 rows of 10 hex bit storage openings (minus screw locations) in a honeycomb arrangement.
14
88
0
521
updated February 28, 2024

Description

PDF

I was looking to store a variety of hex bits and liked the way the honeycomb looked.  I built this new version from scratch, adding dedicated locations for #8 countersunk wood screws.  My printed versions fit together nicely when positioned one above the other (as in the photo) but don't fit together perfectly when they meet horizontally.  It's close, but there is a gap of about half a wall thickness.

Good if you have a fair number of hex bits.  I actually leave spaces between the bits so I can get them out easily.

Printed with PETG, 0.2mm layer.

Tags



Model origin

The author remixed this model.

Differences of the remix compared to the original

I built this new model from scratch, but copied the idea.  I've changed the angle so the bits are flatter relative to the wall and have added specific screw locations.
