Innomaker camera support for PRUSA mk3s+

Fine-tuned support for 5MP Innomaker camera (no vibrations!)
4
22
1
157
updated February 27, 2024

Description

PDF

Quite straightforward, can be printed in PLA. it is designed not to have any vibrations and to precisely see the nozzle all over the plate, many iterations in angle and position! Admittedly, the camera has a good quality but the depth of focus of the camera with the standard lens is limited, so expect that in the nearest position focus won't be perfect.

Tags



Model origin

The author remixed this model.

Differences of the remix compared to the original

one part, the camera frame,  is a modification of https://www.printables.com/model/535745-innomaker-camera-mount-compatibel-with-articulatin and the fixation to the x-axis motor is a modification of https://www.printables.com/model/46866-prusa-mk3s-mk3s-pi-camera-v21-mount-with-optional-/files. The arm is original and designed for minimal vibration.
