Azteeg X3 stepper driver 40mm fan bracket

2014/03/02 Update: The customizer file had no closed surface. Uploaded a netfabb fixed version

Customized version of http://www.thingiverse.com/thing:166045

Customized to fit the Panucatt Azteeg X3 controller on a Bukobot 8 V2 duo. It additionnaly stops the wireguide of the printhead to hit and detach the heatsinks from the stepper drivers

Clearance for the stepper motor heatsinks is adjusted for Enzotech MOS-C10 copper heatsinks.

http://www.panucatt.com/Azteeg_X3_reprap_3d_printer_controller_p/ax33dp.htm http://www.bukobot.com/

Instructions

Printed on a Bukobot 8 V2 duo with PLA .15mm layer and 50% infill on Avery J8567 clear inkjet shipping label @65°C bed

The slow running (and thus quiet) fan shown keeps the stepper drivers perfectly cool, even the two outermost which are not in the direct air flow.

The following options were used for the customizer:

bracket_length = 10

pcb_width = 51.5

bracket_thickness = 3.0

fan_hole_spacing = 32

bracket_height = 23

screw_diameter = 3.9

cross_bracket = 5

fan_size = 40
