X230 USB-C adapter

This adapter fits the ZYPDS USB-C 20V adapter.

https://www.aliexpress.com/i/1005005394532061.html  (Mini Single Function)

Allowing you to power your thinkpad with a modern 65W 20V 3.25A charger or powerbank.

Red wires to positive, black to negative, blue disconnected (fakes a 90W charger). Can route blue through a 10k resistor to negative, providing a 65W data signal to the main board if you wish.

Print Settings

• Printer brand:

Prusa

• Printer:

I3 MK3S

• Rafts:

No

• Supports:

No

• Resolution:

0.1mm

• Infill:

50%

• Filament brand:

AMZ3D

• Filament color:

Black

• Filament material:

PETG

• Notes:

Print the plug with the chamfer up, print the usb-c adapter with the round face up.
