simagic pins usb passthrough mod

this print allows you to make a pogo pin holder to use with your simagic qr or nrg style to have usb passthrough. i drilled a hole and ran the usb cable through shaft extension to qr and soldered it to pcb so i had 4 channels for usb signal ans power. you have to seperate the pcb rings as 2 of them are joined together, i just used a dremel with tiny tip to grind away contact.

here is a link for the pogo pins i used https://a.co/d/9Sdmixw

heres a link to the qr also comes with pcb.

https://www.ebay.com/itm/404638757428?mkcid=16&mkevt=1&mkrid=711-127632-2357-0&ssspo=f5vfvis7sbg&sssrc=2047675&ssuid=&widget_ver=artemis&media=COPY
