Zortrax M200 Bed Knob

The Project

I have get the idea from this;

This is a remix from: https://www.thingiverse.com/thing:4305456

Inside I have inserted an M3 nut.

You must measure and modify the project with the right measure for your knob.

I shared fusion 360 model and ou can change all dimensions.

With this knob you can adjust the plate more easily and more precisely thanks to the rhombus-shaped marks present in each quadrant.

ATTENTION:

⚠⚠⚠ If you use a nut version put the pause at right heigh ! ⚠⚠⚠

better if you adjust all the measurements according to the nut used

Update 2021/01/26

Added new version with ruthex threaded insert.

In this case you can prith without pause and add insert after printing

Print Settings

Printer Brand:

Zortrax

Printer:

M200

Rafts:

Yes

Supports:

No

Resolution:

0.09

Infill:

90%

Filament: z-abs ABS Red
