Filament guide mount for Sovol SV06

This is a mount for a filament guide that fits a Sovol SV06. It replaces the built-in filament holder on top of the machine, and is useful if you want to feed in filament from off the machine (e.g. in a dry box). You can reuse the same screws from the filament holder.

The bore snugly fits a standard 4mm OD teflon tube. You can feed in a tube from one end or both ends. Adding a tube will help prevent the filament from wrapping around a part of the printer and getting tangled.

There's an slightly protruding ring in the middle of the bore, so tubes will stop at the halfway point. (This ring means that if you put a PTFE tube between this mount and the extruder, it will stay the same length – without it, the tube might creep through the bore since it's under compression, which would pull the tube away from the extruder.)

Printed in PLA with 0.2mm layer height, no support.
