Wera Gridfinity Screwdriver Rack 1x2 anti-Wobble

Gridfinity rack for Wera micro screwdrivers. I added an additional style base for true anti-wobble protection.
11
56
2
321
updated March 24, 2024

Description

PDF

Screwdriver rack for up to 8 Wera micro screwdrivers. The new base allows for some additional stability. Shortening the legs doesn't work for sets where there is a lot of length variability in the screwdrivers.

Per original maker:

When printing the legs, rotate them so the flat part is facing the bed. e.g. 45° on Z axis, 90° on Y axis. No supports are needed.

There are no tolerances built into the design, so fitting the legs takes some work. Use a sandpaper or a file on the stubs to make it easier.  *I've been able to tap the legs into place without any sanding. The fitment eliminates the need for glue in the model.

Tags



Model origin

The author remixed this model.

Differences of the remix compared to the original

This is an additional base that provides additional support to keep the screwdrivers even more stable. This works well in a set of mixed length screwdrivers.
