1515 Blind Joint Assembly Jig 3 Extrusions
1515 Blind Joint Assembly Jig for 3 Extrusions. I use it for 1515 printer assembly but do what you want with it :D
8
51
0
267
updated February 5, 2024
Description
PDFWas pretty happy with the Original Design and it worked really well. I thought i would also add a bit more length and a third extrusion too the mix. The holes are designed for M3 Heatsets so you can screw the block onto the Assembly jig and squeez in the extrusion.
I used the 2.5mm hole version for this remix.
Tags
Model origin
The author remixed this model.
Differences of the remix compared to the original
Extended the length a bit
Added the option for a third extrusion, squeezed in by a block.
