SKR mini E3 mount for Anet A8

A simple mount to allow the new SKR mini E3 to be mounted on the Anet A8 stock frame.

I printed it in PETG, but I'm sure any material would be fine.

Depending on your printer tolerances, you might need to change the size of the screw holes

The last photo is for the LCD mod to convert it to 3.3V. I built a small regulator from parts I had on hand, but I'd just recommend using a Linear regulator like the LM1117mp-3.3. Just cut the top 5V track and then connect the regulator as shown in the photo.

For more information on getting the SKR mini E3 working with the stock Anet A8, see my youtube video: https://www.youtube.com/watch?v=ftRg0S-_qts&t=405s

Print Settings

Printer Brand:

Anet

Printer:

A8

Rafts:

Doesn't Matter

Supports:

No

Resolution:

0.2mm

Infill:

30%

Filament: Generic PETG Black How I Designed This ===================

Designed in Solidworks using the SKR mini E3 diagrams on github
