Peter Grifffin Medallion Optimized for Detail

Split the medallion so you can print peters with higher resolution
4
64
0
472
updated February 13, 2024

Description

PDF

I was very happy with the original model, but I don't like sanding my parts so I found a way to split the face from the rest of the coin to print the face in higher quality.

Can print the medallion shell normally, but for printing Peter's face I added snug supports and a brim so that it wouldn't come off of the build plate during printing. It has a very small contact area so this is probably required. Gluestick and printing slow can help too if there are adhesion issues. The face should be printed vertically, like how it is oriented in the 3mfs I uploaded, as model's generally have finer detail on the z-axis. This achieves a much smoother result that requires less post-processing, if any.

I included 3mf files for both Prusaslicer and Bambuslicer, so download the 3mf for your respective slicer. These are the only 2 slicers I tested, so I am not sure if others will work. I used negative parts to separate the parts, which you will be able to see when importing the 3mf.

You will need a very small dot of superglue or other adhesive to attach the face back to the medallion.

Thanks to the original creator for uploading this!

Tags



Model origin

The author remixed this model.

Peter Griffin Medallion
by JohnDFishing
Original model was switched to draft or deleted

Differences of the remix compared to the original

The face is split from the medallion to make printing easier
