Make the Ultimate Bluetooth Dry Ice Fog Machine

I recently needed a Dry Ice machine for some theatrical effects for a local show. Our budget would not stretch to hiring in a professional one so this is what I built instead. It's mostly 3D printed, controlled remotely via Bluetooth, battery-powered, portable and includes LEDs for fun effect. You can even design your own nozzle to create different fog patterns.I've included two nozzle designs of my own for you to try.

It works great as a stage effect and will be a hit at any Halloween parties.

Print instructions

If you prefer to follow an instructional video then I have created one which you can watch. It's also great if you want to see what this machine is like - I show both types of nozzles that I designed at the beginning of the video: https://youtu.be/IhL9i5he0LY

Written instructions: https://www.instructables.com/id/Ultimate-Dry-Ice-Machine-Bluetooth-Controlled-Batt/

List of items used in this project and where to find them (the links are Amazon affiliate links and help to support this channel at no cost to you):

■ Elegoo Arduino Nano (x1): https://geni.us/ArduinoNanoV3
■ L298N Motor Driver (x1): https://geni.us/L298N
■ 8 AA Battery Holder (x1): https://geni.us/8aaBatteryHolder
■ AA Batteries (x8): https://geni.us/AABatteries
■ Mini breadboard (x1): https://geni.us/MiniBreadboard
■ 12v Geared DC Motor (x1): https://geni.us/12VGearedDCMotor
■ HM10 Bluetooth Module (x1): https://geni.us/HM10Bluetooth
■ Contact Switches (x2): https://geni.us/ContactSwitch
■ Stationery Holder (x1): https://geni.us/StationeryHolder
■ Nuts and Bolts: http://geni.us/NutsAndBolts
■ Wire: https://geni.us/22AWGWire
■ PLA Filament: https://geni.us/PLAFilament
■ Plastic Container (x1): https://geni.us/PlasticContainer

==========

The code and wiring diagram can be downloaded from here: https://diymachines.co.uk/projects/bluetooth-controlled-dry-ice-machine.html
