Voron V0 CYD Screen Mount

Quick model of a ESP32 CYD Screen for the V0
11
52
2
571
updated January 27, 2024

Description

PDF

Quick CYD screen I made to mount to a Voron V0.2 (might work on earlier versions but I only have the V0.2)



Uses CYD-Klipper on the ESP32 to get a cheap screen for the V0 as I hated the old school one that it came with - https://github.com/suchmememanyskill/CYD-Klipper



You will need to get the front piece from the original Pintable's page - https://www.printables.com/model/645166-esp32-28inch-touch-ips-cyd-lcd-screen-case



Needs supports, especially under the front lip where the front case snaps onto the back.

Tags



Model origin

The author remixed this model.

Differences of the remix compared to the original

Merged the back piece to mount to a Voron V0
