ATX Cable Machine 60.5x60.5mm hole beam hooks

These hooks fit on ATX Cable machines with hole beams of 60.5x60.5mm size and holes 20mm in diameter spaced 50mm apart.

• Material: PETG
• Infill: 100% concentric
• Top and bottom layer: concentric
• 8 grams of filament per hook
• Print time: 10x on a plate 3 hours on Bambulabs X1C

Hooks are tested with 20kg on a 8mm carabiner, no significant deformation when the carabiner is at the base of the hook or at the tip over a hang time of 20 minutes.

The hooks snap into the holes and are in place securely once installed.
