Case for 0.91 128x32 OLED

I wanted to add an OLED to my custom ergonomic keyboard, but there wasn't a great place on the case. This is a simple solution.

Two versions. The original is thicker with a wider bezel. It's easier to print and work with, but a little clunkier looking. V2 takes everything about as thin as I can reliably print and still fit wires through the stand shaft. It did take a little trimming of the top clip of the stand shaft.

Notice that the orientation matters - the display is not quite centered on the board. Look carefully at the display and you can see what I mean.

Fits these OLEDs: https://www.amazon.com/gp/product/B08ZY4YBHL/ref=ppx_yo_dt_b_search_asin_title?ie=UTF8&psc=1

Source files if you want to remix:

V1 https://cad.onshape.com/documents/8bb13b85b630aa236585470f/v/116605f43693a6f22119f48d/e/9af1519f5ed597d638d0a95f?renderMode=0&uiState=650e483b17712a6b813197fa

V2 https://cad.onshape.com/documents/8bb13b85b630aa236585470f/v/427a5aab91d3741e68943523/e/9af1519f5ed597d638d0a95f?renderMode=0&uiState=650e3ec817712a6b81316e8d

Print Settings

Printer Brand:

Creality

Printer:

Ender 5

Rafts:

No

Supports:

No

Resolution:

.12mm

Infill:

Not thick enough to matter

Filament: Kingroon PLA Black

Notes:

I printed with the face down, back down, and stand laying on its clip.

Category: Electronics
