Battery powered 92mm PC Cooler

Battery powered 92mm PC Cooler

Desktop cooler can be used as tool shen soldering, engineering and many other situations.
Assembly process is simple, but you need to insert wires gently, because tight fit of everything.

If you want to apply some slicer options to outside walls (like me apply fuzzy skin), you can use mask file to apply effect correctly.

Needed components:
- 92mm PC Cooler
- DC-DC Step-Up module
- Type-C TP4056 Lithium Battery Charger Module With Protection
- Slide Switch SS-12F15
- Thin cable, about 1m
- M2x12mm self-tapping screws
- Any LiPo battery. I'm using battery from disposable wape.

Wire length recomendations:
Cooler[+]     ->  Step-Up[Out+]  = 88mm
Cooler[-]     ->  Step-Up[Out-]  = 88mm
Switch[2]     ->  Step-Up[In+]   = 58mm
Charger[Out+] ->  Switch[1]      = 31mm
Charger[Out-] ->  Step-Up[In-]   = 94mm
Battery[+]    ->  Charger[B+]    = 210+mm
Battery[-]    ->  Charger[B-]    = 210+mm

Example links for order:
- MT3608 DC-DC Step-up Board Converter Module Adjustable Booster Power Supply Module Voltage Regulator 2A Max 2V-24V To 28V
https://a.aliexpress.com/_EuzLkHf

- Type-C Micro Mini 5V1A 18650 TP4056 Lithium Battery Charger Module Charging Board With Protection Dual Functions 1A Li-ion
https://a.aliexpress.com/_EJslVpT

- Slide Switch Micro-power Toggle Switch Single and Double-row Direct-inserted Horizontal Sliding Second Gear Third Gear
https://a.aliexpress.com/_EztahGp

- Small Micro Carbon Steel Black Cross Phillips Flat Countersunk Head Self Tapping Wood Screws
https://a.aliexpress.com/_EG3JCfj
