control panel for lack enclosure

Control panel for enclosures from IKEA Lack table suitable for Expandable Steel Sheet Holder
13
34
0
721
updated July 9, 2021

Description

PDF

Control panel for enclosures from IKEA Lack table suitable for Expandable Steel Sheet Holder.

Rocker switches with the dimensions 15 x 10mm can be inserted into the openings on the left.

The frames are glued into the two recesses. This results in a certain protection against unintentional actuation.

Update:
I had to adjust the cutouts for the rocker switches. That was a design flaw on my part. The switches fell through the hole. With version 2 the switches now fit.
