Generative Design Bellcrank

Fusion360 Generative Design Bellcrank, based on FSAE/formula student racecar CNC aluminum bellcrank dimensions.
4
31
0
194
updated January 6, 2024

Description

PDF

This was my best attempt at generative design, in Fusion 360. I defined several load cases in different directions, and added some wall thickness constraints. It then built material between the cylinders.

What I found cool was that it converged on a “twin I-beam” design all by itself.
