Simple wall mount for the Anker Power Expand 5in1 Thunderbolt Hub

I wanted to clean up my desk a bit and rigidly mount my Anker USB-C hub to the side of my monitor stand. Went with screws because the hub gets just warm enough to soften the adhesive on command strips.

  • Mounts using 2 counter-sunk screws sized #6 by 0.5in long.
    • Some options from McMaster if you need them here
  • The screw hole will clear screws with head diameters up to 7.5mm/0.3in and screw threads 3.75mm/0.15in diameter

I decided to make the USB-C to computer plug captive but I've included the STEP file in case anyone wants to change that.
