Kywoo Tycoon Max Belt Cover/Pulley Cover/Beard Savior 9000

I created this as a belt cover for the Kywoo Tycoon Max. I was having issues with my beard getting caught in the pulley.
2
19
0
141
updated January 4, 2024

Description

PDF

I created this as a belt cover for the Kywoo Tycoon Max.
I was having issues with my beard getting caught in the pulley and being ripped out while observing the first layer. I got sick of this.

So here we go.. The Beard Saver 9000/Belt Cover.

I have Uploaded two versions, On with, and one without the Text.

*EDIT*

I Made a new bolt on Design.

This model allows standard T-Slot Nuts and bolts to be used.

Like the ones used to attach the spool holder

https://www.amazon.com/gp/product/B0BZP8T639/ref=ppx_yo_dt_b_asin_image_o00_s01?ie=UTF8&th=1

I would upload one for the Standard Tycoon/IDEX, but I do not have the measurements between the bed rails. If anyone wants to comment the width, I will upload a version for that one.
Hopefully this saves someone from Beardache.

.2 Resolution

PLA

40% Infill or whatever, doesn't matter much

  • Notes:

I used Ironing in my picture, while it looks nice, it caused the fit to be a bit looser than expected. The non Ironed one was a snug fit. Not sure why. Also the words “Savior” are a bit messed up, the color didn't flow at all on the first layer, only the second. Still trying to work through HUGE BLOB prevention between color shifts. (I retracted TOO much)
