Passthrough for AN Hose
A passthrough I designed for a customer
Allows multiple AN lines 3 -6AN, 2 -12AN, and 2 -10AN lines through
10
21
0
184
updated December 23, 2023
Description
PDFPassthrough to allow transfer of 7 AN lines total through either a firewall, backseat, or trunk liner.
Used on a customers MKV supra to separate and pass through fuel lines and rear mounted auxiliary cooling lines.
3 -6AN lines
2 -12AN lines
2 -10 AN lines
Can happily make more models utilizing different hole sizes and different lines.
Can also be utilized for wires if adapted properly
Tags
Model origin
The author marked this model as their own original creation.
