IP5328P Power Bank module case (5x 18650 cell)

IP5328P module case

This is a remix of 3D printed case for very popular IP5328P power bank module.

This module supports 18W of charge/discharge and is capable of delivering 12V at the output.

I made a remix to be compatible with the M3 inserts and bolts.

Parts needed

• 8x M3 Threaded Insert (4.6mm x 5.7mm)
• 4x M3 Screw 10mm length (or similar)
• 4x M3 Screw 3mm length (or similar)

Notes

This is a very easy and fun build, I made a couple for myself and friends.

The power bank module itself is very reliable, it does not overheat and I can easily power projects that use 12V output with a USB C- PD decoy module.

Print Settings

Printer Brand:

Creality

Printer:

Ender 3

Rafts:

No

Supports:

No

Resolution:

0.2mm layer (0.6mm nozzle)

Infill:

20%

Filament: Jayo (Black) / Fiberlogy (Blue) PET-G

Category: DIY

Changing to M3 threaded inserts and bolts.
