Brush gears for LG Hom-Bot VR64701

After the brushes on my Hom Bot stopped turning, I went looking for the fault. The fault was 2 destroyed gears in the gearbox of the brush drive. I determined the dimensions by making several test prints, the beta angle of 25° looked the best.

Print Settings

Printer Brand:

Creality

Printer:

Ender-3 S1 Pro

Rafts:

No

Supports:

No

Resolution:

0,12

Infill:

50%

Filament: eono PETG White

How I Designed This

FreeCAD FCGears Addon

• involute gear
• beta 25°
• traverse_module 0,57mm
• rest are default

Category: Replacement Parts
