Alternative Effector for Anycubic Kossel V5

Goal is a light weight effector to optimize print quality and empower others to do it better ;-)

Version 4 enables better flexibility with the fans, You may blow with the axial fan into the radial fan to enforce the cooling.

Version 9 is a usable head, next iteration will have an movable or exchangeable air duct.

and it has

Print Settings

Printer Brand:

Anycubic

Printer:

Kossel

Rafts:

No

Supports:

Yes

Resolution:

.2

Infill:

15%


Filament:
at your liking PLA, PET, ASA colorfull :)

Notes:

You need support on both versions at least for the Kabelführung

There is potential for making the head even lighter. Printing without infill, thinner walls, reduce the size of the hotend ;-)

Post-Printing

Category: 3D Printer Parts
