Case for SONOFF WiFi Switch Module

This is a case for the SONOFF 5V/12V Inching/Self-Locking WiFi Switch Module
3h 46m
5× print file
0.15 mm
0.40 mm
32.00 g
4
41
2
400
updated May 18, 2021

Description

PDF

This is a case for the SONOFF 5V/12V Inching/Self-Locking WiFi Switch Module such as this one oLikewisen Amazon.  It features cutouts to access the wire terminals, a hole for the Micro-USB power, as well as buttons and light pipes for the LEDs.

The lid is provided with both break-away supports in the countersunk screw holes, and without.  I had no issues breaking them out but your printer may vary.  Likewise, I have included the buttons with a brim and without.  The one with the brim is intended to be printed with the bottom layer in concentric rings to allow tear-off.
