Hello,

I would like to present my version of the dry box.

I was inspired by this model: Link to the model

In all the boxes I've seen so far, the spools are upright. This bothered me a lot, so I came up with a horizontal variant. The box offers the possibility to accommodate various spools but requires an adapter ring to compensate for the spool hole. It is suitable for spools with a diameter of 200 mm and a thickness of 70 mm. As I mostly use eSun or Bambulab spools, currently, I only need one size, which is 54 mm. Upon request, I can create more sizes, or you can design your own. The inner hole is 26.2 mm in diameter.

For the roller, you will need a 608 ball bearing, and for the filament outlet, a PC4-M6 connector is required. If you need a display, I used this one: Link to the product on Amazon.

It's recommended to print the sealing ring in TPU. Filament can be chosen as desired. I used PLA.

German
---------------------------------------

Hallo,

ich m\u00f6chte gerne meine Version der Trockenbox vorstellen.

Ich wurde durch dieses Modell inspiriert: Link zum Modell

In allen Boxen, die ich bisher gesehen habe, stehen die Spulen aufrecht. Das hat mich sehr gest\u00f6rt, daher kam ich auf die Idee einer horizontalen Variante. Die Box bietet die M\u00f6glichkeit, verschiedene Spulen aufzunehmen, erfordert jedoch einen Adapterring, um das Loch der Spule auszugleichen. Sie ist geeignet f\u00fcr Spulen mit einem Durchmesser von 200 mm und einer Dicke von 70 mm. Da ich meistens Spulen von eSun oder Bambulab verwende, ben\u00f6tige ich momentan nur eine Gr\u00f6\u00dfe von 54 mm. Auf Anfrage kann ich jedoch auch weitere Gr\u00f6\u00dfen erstellen oder Sie k\u00f6nnen diese selbst anpassen. Das innere Loch hat einen Durchmesser von 26,2 mm.

F\u00fcr den Abroller wird ein 608 Kugellager ben\u00f6tigt und f\u00fcr den Filamentauslass ein PC4-M6 Stecker. Falls Sie ein Display ben\u00f6tigen, habe ich dieses benutzt: Link zum Produkt auf Amazon.

Es wird empfohlen, den Dichtungsring aus TPU zu drucken. Das Filament kann nach Wunsch gew\u00e4hlt werden. Ich habe PLA verwendet.
