Prusa XL series: Antiresonance integrated steel sheet holder (curved) (Update: Added 3 sheet version)

I modified the original and fantastic idea from wolffaayyy here on printables.
I modified the sheet mount, so that it only has 2 Steelsheets instead of 3 (most of us will probably only have 2. Also a modified it with a better tray opening, so that it is easier to insert steel sheets!

This version has 2 Position mounts , so that you can decide, if you like them more in the front or in the back. if you mount it in the back, you have additionally the possibility to screw it in with a T-Nut into the frame.


The combination of screwing it in the back and the curve of the sheet mount, prevents the sheet of vibrating in the mount.

iMPORTANT: There are 2 Support structures that you can use in pla/petg support compination. Remove them if you wanna use regular aupport

After many asked me how they could support me, you can now

Tip me on KO-FI by klicking here:

                                                      https://ko-fi.com/surfalex2000

Check out my other optimized XL Parts! There is a Series to come!

You can find them in my Collection:
https://www.printables.com/@Surfalex2000/collections/830114

Tags

Curved sheet rack, with mount in the back
