CR10 Top Spool Mount - Improved
Description
PDFThis is a remix.
Improved the strength of the part, reconnected the spindle to the shaft (was weirdly disconnected) and added a rim to the end of the spindle to help catch the spool if it gets shaken to the edge. Also included a mirrored version so that you can print the optimal orientation for your printer. Clips over the top frame extrusion and has a hole in the top for an M5 bolt and T-nut to fit into.
ORIGINAL MODEL: https://www.thingiverse.com/thing:4484841
Tags
Model origin
The author remixed this model.
Differences of the remix compared to the original
Improved the strength of the part, reconnected the spindle to the shaft (was weirdly disconnected) and added a rim to the end of the spindle to help catch the spool if it gets shaken to the edge. Also included a mirrored version so that you can print the optimal orientation for your printer. Clips over the top frame extrusion and has a hole in the top for an M5 bolt and T-nut to fit into. Recommend printing at 15-20% infill.
