R/C Shockabsorber Fillingstation

Shockabsorber Fill Table for R/C shocks

This little tool takes r/c car shockabsorbers from roughly 1:10/1:8 scale cars with a diameter up to 11,5mm through the filling process.

I own a Traxxas TRX-4 and it is tailormade for its shockabsorbers (Ø11 x 90mm), but it should work for similar shocks also, if they have upper springholders to rest on.

The free hight below the desk is about 90mm.

The table has little edges around all holes to reduce the mess, but in my experience (i changed the oil for the first time now) it is not nessessary, no real mess.

The legs are press fitted and stable enough for my needs, you might want/need to sand/glue them into the desk dpendend on your printers precision.

You might need to print 2 (two) pieces of the leg part. :-D

Print Settings

Printer Brand:

Prusa

Printer:

I3 MK3S

Rafts:

Doesn't Matter

Supports:

No

Resolution:

0.20

Infill:

10%

Filament: Prusament PETG

Notes:

I used PETG, but i think it does not matter - PLA will be also fine.
