FT EMS SWC V2 for Smaller Print Beds

This is a remix of Fizzy's EMS for the Ender/Switchwire conversion. It's been modified to print on smaller bed sizes (200mmx200mm minimum).

Modifications include:

• Main section split into 4 smaller sections (PSU main, PSU subframe, electronics main, electronics subframe)
• Cable duct split in 2 to allow PSU side and electronics side to mount on the y extrusion
• Heat set insert and screw holes added to join main and subframe sections (same concept of Fizzy's original EMS design)
• Designed subframe clamp to allow both subframes to mount to the y extrusion
• Area behind the power input of rear frame removed
• Corner of rear section removed to allow wiring/cables from the z chain to passthrough

All instructions and print settings remain the same. In addition to the original BOM, this remix requires:

1. 4 x heatset inserts for each main frame section
2. 4 x M3x8 screws to join the subframes to their main frame sections
3. 1 x M5x10 BHCS screws to mount the frame

CHANGE LOG

8-Dec-23

1. Fixed an issue found when slicing the main electronics and PSU frames. New files uploaded.

It's been modified to print on smaller bed sizes (200mm x 200mm minimum). The front section has been split and into a psu side and an electronics side. Each side has also been split into a main and subframe. Also, the section of the rear behind the power input has been removed to make it fit on an Ender sized bed.
