Spices Stand

Species rotary stand.

It is designed to organize and optimize the space occupied by the different spices bottles in our kitchens.

Each floor has space for 9 spices bottles.

The pieces are valid for bottles with less than 47mm of diameter (more or less), and less than 140mm of height. If you need to put smaller spices bottles, you can design an adapter for the bottles holes.

Materials

I used two kind of bearings:

• First ones, I used in the base and on axis bottom an 8mm diameter bearings buy in amazon. https://www.amazon.es/gp/product/B01M3PX3R1/ref=oh_aui_detailpage_o02_s00?ie=UTF8&psc=1
• OPTIONAL - And second ones, I usen on top of support and top axis an 4mm diameter bearings buy too in amazon:

https://www.amazon.es/Rodamientos-Bola-Acero-4mm-Di%C3%A1metro/dp/B0050MVZO8

Expand

If you only need one floor you don't need to print axis_bottom and axis_top pieces.

You can print the floors you need. I with three floors. Everything you need to do is to print: axis_bottom, axis_top, moduleBaseSupport and moduleSupport per floor.

Updated

Include bottom block. I printed with flex materials

Print Settings

Printer:

Prusa i3 Hepsteros

Rafts:

No

Supports:

Yes

Resolution:

.25

Infill:

20

Notes:

I printed in PLA and used this settings:

• Structure Type : Lines
• Overhang angle ... : 60
• Fill amount (%) : 10
• Distance X/Y (mm): 1
• Distance Z (mm): 0.15

Post-Printing

Polish

I have printed it in PLA and afterwards I have polished all the pieces with a fine sandpaper of water, especially the holes of the ball bearings, screws and nuts.
