Power Strip Desk Mount

Clamp for mounting a power strip to the edge of a desk at an angle. I guesstimated a 40 degree angle from the desk would be easy to plug in while reaching across the desk. Desk is 1.5 in thick countertop. Clamps around the edge of the desk.

Used adhesive backed rubber pads to stop the clamps from marring the desk or sliding around. No modification of the power strip necessary. Uses existing mounting holes. #4-40 x 1/2 machine screws hold the power strip on. Nuts are slid into the slot and screws put in from the front. Clamps to the desk using a #8-32 machine screw into a nut in a slot

Designed around this power strip. https://www.homedepot.com/p/Defiant-6-Outlet-Surge-Protector-with-6-ft-Cord-White-YLPT-43-6FT/205607072

Using these adhesive backed rubber pads. https://www.lowes.com/pd/Waxman-6-Pack-1-in-x-4-in-Black-Rubber-Pads/3034747

Print Settings

Printer Brand:

Wanhao

Printer:

Wanhao Duplicator i3 Plus

Rafts:

Doesn't Matter

Supports:

No

Resolution:

0.15 mm layer, 1.2 mm shell, 0.6mm top/bottom

Infill:

20%
