Delonghi EC685 funnel (V3)

The Normcore magnetic funnel i bought for my portafilter didn't fit as the magnet weren't sticking to the portafilter very well so i decided to design one by myself, inspired by many funnels that i saw on Instagram, using a rotating lock design ! ☕

V2 UPDATE : Added the red parts in order to avoid using supports and now you can print this thing from the top to the bottom with top ironing (the bottom being the top, it will be smooth and all will slide with ease !), see the .gcode attached file

V3 update : Added a small hollow in order to accept some baskets shapes and shrinked the diameter so coffee stays in place when you take the funnel off the portafilter

Print Settings

Printer Brand:

Creality

Printer:

Ender-3 S1 Pro

Rafts:

Yes

Supports:

No

Resolution:

0.16mm layer height, 0.45mm layer width

Infill:

12% Triangles 0.32mm layer thickness

Filament: Creality Ender PLA PLA As you want
