under-desk organizer system

under-desk organizer system

I was looking for "standard dovetail" dimensions upon which to base a quick-release system for mounting things (cable raceways, hooks for headphones) under the top of my desk. Thus I came across the military picatinny rail system, whose orthogonal ribs especially accommodate my idea of quick-release pins.

The rail itself is directly derived from the "exact dimensions" Picatinny rail template by https://www.printables.com/@LucasF_62480.

System contains:

• 140 mm and 80 mm base rail segments - print laying flat
• End caps (glue on) - print laying flat
• Under-desk cable runway hooks - print laying on the side
• Cable/accessory gutter segments - print standing up/laying on the large "J" profile
• "I" and "U"-Shaped pins to fit even and odd positions of the rail
• Slider template for your remixes
• M4 countersunk washer for your convenience

The silver gutter in my photos is printed in silver 3DJake ecoPLA.

Commercial reproduction of this project is not permitted, due to upstream licensing, and because you shouldn't go freeloading here anyway.

Category: Office
