Description

PDF

[PL]
Moja interpretacja (remix) nakładki na klapkę baterii do popularnych głowic termostatycznych Tuya/Moes. Model został wykonany od podstaw, metodą prób i błędów dobrałem idealną średnicę wewnętrzną i kształt wycięcia na przyciski.
Proponowane ustawienia druku (testowane w Cura):
- warstwa 0.2 mm
- adaptive layers
- wypełnienie 10%, gyroid

[EN]
My interpretation (remix) for the popular Tuya/Moes radiator actuator battery flap overlay/cover. The model was made from scratch, using trial and error I've got the perfect inner diameter and shape of the cutout for the buttons.
Suggested print settings (tested in Cura):
- 0.2 mm layer height
- adaptive layers
- 10% fill, gyroid

Tags



Model origin

The author remixed this model.

Cover Holder for thermostat Moes Tuya HY368
by DivanX10 (thingiverse.com)


Differences of the remix compared to the original

[PL]
Model wykonany od podstaw na bazie oryginału. Dodane ścięcia na krawędziach, dostosowane wycięcie na przyciski.

[EN]
Made from scratch based on the original. Added bevels on the edges, adjusted cutout for buttons.
