Ender 3 Drawer/Pi Combo

Octopi and filament chip Storage Drawer.
6
29
0
386
updated October 31, 2023

Description

PDF

Remixed from:
https://www.thingiverse.com/thing:3416444 -E3 Pro Dual Drawer https://www.thingiverse.com/thing:3719217 -Malolo's Pi Case (Pi 3) https://www.thingiverse.com/thing:3723561 -Malolo's Pi Case (Pi 4) https://www.thingiverse.com/thing:3108748 -Filament Chips
https://www.thingiverse.com/thing:116437 -Pi Logo

I modified DWS_design's drawers to house a raspberry pi in the top drawer. The pi mount is set deeper into the drawer to help hide any cable spaghetti coming from the pi. The mounts are designed for the Raspberry Pi 3 Model B. The back of the drawer has had slots cut out of it for cabling. If you ever decide you want to mount your pi elsewhere it's as simple as swapping out the top drawer. Personally, I store my printer tools for maintenance in a separate drawer. So I modified the bottom drawer to house a compartment for glue sticks, superglue, a "Gripster X-acto knife, and roughly 24 of MaxMuske's Filament chips. There are also 2 other unutilized compartments to hold misc. screws, twist ties, and the like.

You may need to use a mini USB L adapter as some of the thicker USB cables won't fit in this drawer to power the Pi. I have only printed the Pi 3B case, not the Pi 4. assuming the Pi 4 is the same height as the Pi 3 it should work just as well.

If you want easier troubleshooting it may be ideal to knock out another rectangular hole across from the HDMI slot.

EDIT:
Also, I was stupid and didn't consider that the cables could hinder the opening of the drawer. You will definitely need some modifications if you want easy access to the pi. All the tinkerCAD files are linked below so you can modify them to your heart's content.

Master WIP Tinkercad: https://www.tinkercad.com/things/c2XXsyEAag5

Top Drawer With Raspberry pi logo (Pi 3): https://www.tinkercad.com/things/h5Z7vWykOY6

Top Drawer No Logo (Pi 3): https://www.tinkercad.com/things/ka186Q34PDj

Top Drawer With Raspberry pi logo (Pi 4): https://www.tinkercad.com/things/8rUMrxDx6Va

Top Drawer No Logo (Pi 4): https://www.tinkercad.com/things/8H1VGpSD9Lq

Bottom Drawer: https://www.tinkercad.com/things/cBtV7ftYIp8

Base Drawer: https://www.tinkercad.com/things/04DXt4CNCUC

Print Settings

Printer Brand:

Creality

Printer:

Ender 3 Pro

Rafts:

No

Supports:

No

Resolution:

0.16

Infill:

15%

Filament: Eyrone PLA White







Category: 3D Printer Accessories

Tags



Model origin

The author remixed this model. Imported from Thingiverse.

Creality Ender 3 Pro dual drawer
by DWS_design (thingiverse.com)


Differences of the remix compared to the original

I modified the top drawer to house a raspberry pi. I also created organizers in the bottom drawer to accommodate filament chips, super glue,  hobby knives, and other miscellaneous small items.
