adxl345 nozzle mount dragon hf

saw many similar mounts, but nothing suit my dragon hf…

• need 2x M2x8 with self tapping, which should hold way more better than normal
• PLEASE, home first, install, and then testing. home z will damage your adxl board!!!

Installation:

1. mount 2x m2x8 thought the board on the mount
2. Homing!!!
3. unscrew the nozzle
4. place the mount and the board under the heat block, the smaller hole on the screw
5. screw the nozzle back thought the larger hole
6. plug the cable back on

Comparison:

My opinion, the different is not that far…for convenient, i'll prefer testing it via can board
