Perspective Cube (Updated)

This is a solid suspended in a frame. From three perspectives you see the solid as a square, a circle, and a triangle.
5
23
0
278
updated October 19, 2024

Description

PDF

This is a solid suspended in a frame. From three perspectives you see the solid as a square, a circle, and a triangle. Specifically, it is the orthogonal intersection of the right square, triangular, and circular prisms.

Designed parametrically in OpenSCAD. Feel free to adjust the parameters and post your makes! The OpenSCAD model is huge, so scale it down to print.

Printed in PLA+, 0.15mm Quality, 15% gyroid infill, and organic supports on my MK4.

Enjoy!



Updated with a nicer frame!
